Product detail description:

1.Operating Voltage:8~32V

2.Operating Current:<50mA

3.Operating Temperature:-40~150°C

4.Out put signal: Square wave or sine wave

5.Signal duty factor :47+/-5%

6.Inductance distance:0.5~2.5mm

7.Tooth module:2~6

8.Thread fitting:UNF5/8 or M16

9.Connecting Way:two wires or three wires connecting

Feature:

Be used for gear rotation speed measurement, combining the advantage of stable signal,wide range of operating temperature ,small size, simple assembly,etc.
