Smart pressure transmitter
Spec:   Unit:   Memo:
Product introduction :



LPT2800X smart pressure transmitter

 Product Overview:

1.24V two wire, optional with LED display;

2.Zero, span free migration, set;
3.Threebutton operation, simple and fast calibration,LPT2800X Smart pressure transmitter uses high integrated circuit,
complete sensor weak signal acquisition conditioning and loop change,output reliably and accurately.

Technical Specification
Power Supply: DC13~36V
Measure Range: -0.1-0...60MPa
Input Impedance: >1MΩ
Sampling Rate: 5 times/second
Measure Accuracy: ±0.2%FS
Output Accuracy: ±0.2%
Display Range: -1999 ~ 9999
Display Mode: 0.36 inch four red LED
Temperature Drift: <50ppm/°C
Work Temperature: -20 ~ +80°C
Relative Humidity: <85%RH
Consumption: Less than 0.3W(with LED display)
Dimension: 72*92*145mm (1KG)
