Ceramic Pressure sensor

Technical Parameters

1.Measuring Range: -0.1-60MPa

2.Accuracy:0.5%FS

3.Output signal:4-20mA, 0/1-5/10V

4.Supply voltage:5VDC,12VDC,24VDC
5.Thread fitting :1/2NPT,1\4NPT( can be customized )

6.Electrical connection: Aviation connector directly connector

7.Compensate for temperature:0-85 °C

8.Operating temperature: -40-100°C,-20-300°C

9.Safety overload capacity: 150%

10.Load capacity: Current ≤ 500Ω

11.Extreme overload capacity: 200%
12.Temperature drift: 0.02% FS/ °C

13.Protection rank:IP65
